Transistor 2SC2627 C2627

TRANSISTOR 2SC2627 MITSUBISHI RF POWER TRANSISTOR

Type Designator: 2SC2627
   Material of Transistor: Si
   Polarity: NPN
   Maximum Collector Power Dissipation (Pc): 20 W
   Maximum Collector-Base Voltage |Vcb|: 35 V
   Maximum Collector-Emitter Voltage |Vce|: 17 V
   Maximum Emitter-Base Voltage |Veb|: 4 V
   Maximum Collector Current |Ic max|: 2 A
   Max. Operating Junction Temperature (Tj): 175 °C
   Transition Frequency (ft): 175 MHz
   Forward Current Transfer Ratio (hFE), MIN: 10
   Noise Figure, dB: -
   Package: TO128
